>TELEHANDLERS

FORKLIFT,8K LB,42' TELESCOPING

Manufacturer Link: <Click Here>


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Daily: Request Quote

Weekly: Request Quote

Quantity:

Additional Information

Key Specs
Maximum Lift Capacity: 8000 lb / 3628.74 kg
Maximum Lift Height: 41 ft 11 in. / 12.78 m
Maximum Reach: 26 ft 7 in. / 8.1 m
Performance
Drawbar Pull 25000 lb / 11339.81 kg
Frame Leveling 10 Degrees
Lift Capacity at Full Height 6000 lb / 2721.55 kg
Lift Capacity at Max Reach 2200 lb / 997.90 kg
Load Center 2 ft / 0.61 m
Maximum Lift Capacity 8000 lb / 3628.74 kg
Maximum Lift Height 41 ft 11 in. / 12.78 m
Maximum Reach 26 ft 7 in. / 8.1 m
Outriggers or Stabilizers No
Outside Turning Radius 13 ft / 3.96 m
Speed - Maximum Lift 15 sec.
Speed - Maximum Lower 13 sec.
Speed - Maximum Telescope In 14.2 sec.
Speed - Maximum Telescope Out 16.5 sec.
Speed - Maximum Travel 19 mph / 30.58 km/h
Dimensional Data
Ground Clearance 1 ft 6 in. / 0.46 m
Machine Height 8 ft 3 in. / 2.52 m
Machine Length 19 ft / 5.79 m
Machine Width 8 ft 3 in. / 2.52 m
Tire Size 370/75-28
Wheelbase 10 ft / 3.04 m
Power Source
Capacity - Fuel Tank 35 gal. / 132.49 L
Engine Horsepower 110 hp / 82.06 kW
Engine Manufacturer Cummins
Engine Model QSF3.8L Tier 4 Final
Maximum Engine RPM 1500 rpm
General
Axle-Front High Bias, Limited Slip
Axle-Rear Oscillating
Function Pump Type Var Load Sensing Piston
Operating Vehicle Weight 27100 lb / 12292.35 kg
Service Brake Type Wet Multi-Disc
Transmission - Nr Forward Gears Standard 4
Transmission - Nr Reverse Gears 3
Transmission Type Powershift

* Please submit a quote request or call us for pricing or questions about our forklift 8k lb 42 foot telescoping rentals in Artesia CA, Los Angeles, San Diego, Palm Springs, and Southern California.
