>TELEHANDLERS

FORKLIFT, REACH 10K 55'

Manufacturer Link: <Click Here>

Where to find FORKLIFT, REACH 10K 55 in Los Angeles

Image for reference only
Actual item may look different
Click on image for larger view

Click on above thumbnails for alternate view

Daily: Request Quote

Weekly: Request Quote

Quantity:

Additional Information

  • Key Specs
  • Maximum Lift Capacity: 10000 lb / 4535.92 kg
  • Outriggers Up Max Lift Height: 55 ft / 16.76 m
  • Maximum Lift Height: 55 ft / 16.76 m
  • Maximum Reach: 42 ft / 12.8 m
  • Performance
  • Drawbar Pull 25400 lb / 11521.25 kg
  • Frame Leveling 10 Degrees
  • Load Center 2 ft / 0.61 m
  • Maximum Lift Capacity 10000 lb / 4535.92 kg
  • Outriggers Up Max Lift Height 55 ft / 16.76 m
  • Outriggers Up Max Forward Reach 42 ft / 12.8 m
  • Lift Capacity at Full Height 5000 lb / 2267.96 kg
  • Lift Capacity at Max Reach 3000 lb / 1360.78 kg
  • Maximum Reach 42 ft / 12.8 m
  • Maximum Lift Height 55 ft / 16.76 m
  • Outriggers or Stabilizers Yes
  • Outside Turning Radius 14 ft / 4.27 m
  • Speed - Maximum Lift 14 sec.
  • Speed - Maximum Lower 11 sec.
  • Speed - Maximum Telescope In 15 sec.
  • Speed - Maximum Telescope Out 16 sec.
  • Speed - Maximum Travel 20 mph / 32.19 km/h
  • Dimensional Data
  • Ground Clearance 1 ft 6 in. / 0.46 m
  • Machine Height 8 ft 4 in. / 2.54 m
  • Machine Length 20 ft 1 in. / 6.12 m
  • Machine Width 8 ft 5 in. / 2.56 m
  • Tire Size 400/75-28
  • Wheelbase 11 ft 6 in. / 3.49 m
  • Power Source
  • Capacity - Fuel Tank 38.3 gal. / 144.98 L
  • Engine Horsepower 130 hp / 96.98 kW
  • Engine Manufacturer Cummins
  • Engine Model QSF3.8L Tier 4 F
  • Maximum Engine RPM 1500 rpm
  • General
  • Axle-Front High Bias, Limited Slip
  • Axle-Rear Planetary
  • Function Pump Type Load Sensing Piston
  • Operating Vehicle Weight 31559 lb / 14314.92 kg
  • Service Brake Type Wet Multi-Disc
  • Transmission - Nr Forward Gears Standard 4
  • Transmission - Nr Reverse Gears 3
  • Transmission Type Powershift

* Please submit a quote request or call us for pricing or questions about our forklift reach 10k 55 foot rentals in Artesia CA, Los Angeles, San Diego, Palm Springs, and Southern California.
