>TELEHANDLERS

REACH FORKLIFT,12K LB 55'

Manufacturer Link: <Click Here>


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Daily: Request Quote

Weekly: Request Quote

Quantity:

Additional Information

Key Specs
Maximum Lift Capacity: 12000 lb / 5443.11 kg
Outriggers Up Max Lift Height: 55 ft / 16.76 m
Maximum Lift Height: 55 ft / 16.76 m
Maximum Reach: 42 ft / 12.8 m
Performance
Drawbar Pull 25400 lb / 11521.25 kg
Frame Leveling 10 Degrees
Load Center 2 ft / 0.61 m
Maximum Lift Capacity 12000 lb / 5443.11 kg
Outriggers Up Max Lift Height 55 ft / 16.76 m
Outriggers Up Max Forward Reach 42 ft / 12.8 m
Lift Capacity at Full Height 5000 lb / 2267.96 kg
Lift Capacity at Max Reach 3500 lb / 1587.57 kg
Maximum Reach 42 ft / 12.8 m
Maximum Lift Height 55 ft / 16.76 m
Outriggers or Stabilizers Yes
Outside Turning Radius 14 ft / 4.27 m
Speed - Maximum Lift 16 sec.
Speed - Maximum Lower 13 sec.
Speed - Maximum Telescope In 15 sec.
Speed - Maximum Telescope Out 18 sec.
Speed - Maximum Travel 20 mph / 32.19 km/h
Dimensional Data
Ground Clearance 1 ft 6 in. / 0.46 m
Machine Height 8 ft 4 in. / 2.54 m
Machine Length 20 ft 1 in. / 6.12 m
Machine Width 8 ft 5 in. / 2.56 m
Tire Size 400/75-28
Wheelbase 11 ft 6 in. / 3.49 m
Power Source
Capacity - Fuel Tank 38.3 gal. / 144.98 L
Engine Horsepower 130 hp / 96.98 kW
Engine Manufacturer Cummins
Engine Model QSF3.8L Tier 4 Final
Maximum Engine RPM 1500 rpm
General
Axle-Front High Bias, Limited Slip
Axle-Rear Planetary
Function Pump Type Load Sensing Dual Gear
Operating Vehicle Weight 33960 lb / 15404 kg
Transmission - Nr Forward Gears Standard 4
Transmission - Nr Reverse Gears 3
Transmission Type Powershift

Also check the following item(s) related to the above:

* Please submit a quote request or call us for pricing or questions about our reach forklift 12k lb 55 foot rentals in Artesia CA, Los Angeles, San Diego, Palm Springs, and Southern California.
