>TELEHANDLERS

REACH FORKLIFT, 27K LB 33'

Manufacturer Link: <Click Here>


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Daily: Request Quote

Weekly: Request Quote

Quantity:

Additional Information

Key Specs

Maximum Lift Capacity: 26600 lb / 12065.56 kg
Maximum Lift Height: 33 ft 1 in. / 10.08 m
Maximum Reach: 17 ft 7 in. / 5.36 m

Performance

Drawbar Pull 28500 lb / 12927.38 kg
Frame Leveling 8 Degrees
Lift Capacity at Full Height 15500 lb / 7030.68 kg
Lift Capacity at Max Reach 8000 lb / 3628.74 kg
Maximum Lift Capacity 26600 lb / 12065.56 kg
Maximum Lift Height 33 ft 1 in. / 10.08 m
Maximum Reach 17 ft 7 in. / 5.36 m
Outriggers or Stabilizers No
Outside Turning Radius 14 ft 8 in. / 4.47 m
Speed - Maximum Lift 16 sec.
Speed - Maximum Lower 11 sec.
Speed - Maximum Telescope In 14 sec.
Speed - Maximum Telescope Out 12 sec.
Speed - Maximum Travel 17 mph / 27.36 km/h

Dimensional Data

Ground Clearance 1 ft 5 in. / 0.43 m
Machine Height 10 ft / 3.05 m
Machine Length 20 ft 9 in. / 6.32 m
Machine Width 8 ft 2 in. / 2.49 m
Tire Size 17.5-25 Air CAMSO L2
Wheelbase 11 ft 10 in. / 3.61 m

Power Source

Capacity - Fuel Tank 43 gal. / 162.77 L
Engine Horsepower 160 hp / 119.36 kW
Engine Manufacturer Cummins
Engine Model Cummins QSB4.5L Tier 4 F
Maximum Engine RPM 2200 rpm

General

Axle-Front High Bias, Limited Slip
Axle-Rear Planetary
Function Pump Type Load Sensing Piston
Operating Vehicle Weight 38775 lb / 17588.04 kg
Service Brake Type Wet Multi-Disc
Transmission Type Hydrostatic

* Please submit a quote request or call us for pricing or questions about our reach forklift 27k lb 33 foot rentals in Artesia CA, Los Angeles, San Diego, Palm Springs, and Southern California.
